# Automated Differential Equation Solver Based on the Parametric Approximation Optimization

## Abstract

**:**

## 1. Introduction

- We stick to the known physical “blocks”, i.e., a pre-defined set of terms that appear in conventional equations. Moreover, we may impose a pre-defined form, such as ${u}_{t}=F(u,{u}_{x},{u}_{xx},\dots )$ in [4,5]. In this case, we should manually or automatically add additional terms, such as $u\frac{\partial u}{\partial t}$, covering all possible combinations. Separately, we manually add different types of non-linearities;
- We evolve the equation with manually added relatively small parameterized blocks; for example, all derivatives of the initial data field up to a certain order (within the optimization process) are combined in products to form the equation. An example of such an approach is [3]. In this case, we do not assume any form of the equation and may add the grid-variable coefficients to the search space. The evolutionary algorithm combines partial derivatives and other functions as building blocks to build various equations.

## 2. Related Work

#### 2.1. Classical Differential Equation Solvers

#### 2.2. Towards an Automated Solution

#### 2.3. Neural Network Solvers

- Prepare equation and boundary conditions to a conventional form;
- Form a loss function for training;
- Train a model to minimize the loss function.

**One**of the features is an automated loss-function generation (as it is done in DeepXDE [27] for neural networks using automatic differentiation) for several types of differentiation for a given parameterized model.

**second**feature. To preserve generality, we should move from a classical understanding of a PDE initial-boundary value problem, the ODE initial-value problem, and the ODE boundary-value problem to an optimization problem of a parameterized model in a corresponding Sobolev space using an equation-induced norm together with the boundary value-induced regularization. We use PINN as a base but move towards an equation-type agnostic method.

**third**feature is the overall time of the optimization reduction; we must be able to reuse archived results to increase the optimization time. The latter is done because, in the equation discovery application [28], we are interested in how the given equation solution corresponds to the initial data, rather than the solution itself. During the discovery process, we obtain a large number of candidate equations, and it is desirable to solve them all within a reasonable time.

**fourth**and final is the “automatization” part. Once the algorithm parameters are selected to achieve the desired balance between precision and optimization time, the goal is to solve the equations generated during the discovery process without any need for human interaction.

## 3. Mathematical Problem Overview

## 4. Proposed Approach

#### 4.1. Theoretical Formulation

#### 4.2. Numerical Realization

**General numerical equation solution.**The following questions should be answered to solve the problem using any numerical PDE solution method:

- How is the function represented?
- How do we take the derivative?
- How do we obtain the approximation parameters of the solution?

**Proposed method.**We choose the approximation form, determine how to take differentials with it, and optimize parameters to implement the automated solver. We briefly overview these steps in this section.

- (i)
**Parametric optimization.**As the first component of the numerical solution, we attempt to approximate the solution $u(x,t)$ of an equation $Lu=f$ with a continuous parameterized function $\overline{u}(x,t;\Theta ):{R}^{2}\to R$ that is represented by the parameterized model. The parameter set $\Theta =\{{\theta}_{1},\dots {\theta}_{N}\}$ is an arbitrary set that determines the pre-defined function form. As the most straightforward example, $u(x,t;\Theta )={\theta}_{1}x+{\theta}_{2}t+{\theta}_{3}$ represents a linear regression. Moreover, it could be a neural network. In this case, the method is an extension of PINN-like models.- (ii)
**Model-agnostic differentiation.**As the second component, we use finite-difference schemes, such as Equations (9) and (10), and automatic differentiation as equivalent choices. We explicitly build the finite difference schemes and combine them to apply operators for higher-dimensional derivatives in order to speed up computation.- (iii)
**Sobolev space optimization.**To find the parameter set $\Theta =\{{\theta}_{1},\dots {\theta}_{N}\}$, we use the formulation of the problem described in Equation (7) in the form (11).$$\underset{\Theta}{min}\left[\left|\right|\overline{L}\overline{u}(x,t;\Theta )-{f\left|\right|}_{i}+\lambda \left|\right|\overline{B}\overline{u}(x,t;\Theta )-g{\left|\right|}_{j}\right]{|}_{X}$$

#### 4.3. Modular Approach

**operator encoding**module includes two approaches for translating the fixed input form into the loss to optimize the model weights. The first approach considers

`PyTorch`-based models, which could be either neural networks or simpler linear regression models. In the second approach, the model is represented as the values at the given grid point values, i.e., matrix or, in general, tensor.

**differential approximation**and

**boundary condition approximation**modules.

`PyTorch`models may be differentiated using Autograd or finite differences, whereas matrix-based models may be differentiated using only finite differences. The latter approach, in some cases, is faster since the matrix computations are used.

**optimization**module. Standard built-in

`PyTorch`optimizers are used for this purpose.

#### 4.4. Caching of Approximate Models

**initial field interpolation**module shown in Figure 3. The effect of the initial guess for optimization is shown in Section 5. It is performed as a “cache” of models for neural networks. As an initial step for every algorithm run, we search the library for the model of the same or another architecture with the lowest Sobolev space norm (sum over all grid points X of the functional in Equation (11)) for the given equation and boundary conditions. If the model architectures are different, we train the input architecture on values of a “cached” one.

## 5. Numerical Experiments

- Cache allows converging faster;
- Adding points to the grid leads to a better solution;
- The error between the exact and obtained solutions is negligible for equation discovery application.

`TEDEouS`.

`DSolve`or

`NDSolve`as the exact solution, unless otherwise stated.

#### 5.1. Ordinary Differential Equations

#### 5.1.1. Legendre Equation

`cache=false`) and with the (

`cache=true`) caching technique (see Section 4.4) for 10 runs, as shown in Figure 4 (left).

**Linear model optimization.**To reduce errors and show different modules, as seen in Figure 3, we utilized the matrix differentiation prototype. The results for the same grid setup for the Legendre Equation (12) are shown in Figure 5.

#### 5.1.2. Painlevé Transcendents

#### 5.2. Partial Differential Equations

#### 5.2.1. Wave Equation

**Non-physical boundary conditions**. We assess the convergence of the algorithm for PDE problems. As the first example, we solve the wave equation with boundary conditions in the form of Equation (14). We understand that such conditions seem non-physical. However, as mentioned in the introduction, the main application of the method is data-driven equation discovery. We usually only have the observation field without any information about derivatives. This explains the choice of the boundary condition type for this experiment.

**Physical boundary conditions**. The problem Equation (14) is equivalent to a more physically significant problem, as shown in Equation (15).

#### 5.2.2. Heat Equation

#### 5.2.3. Korteweg–de Vries Equation

**Non-physical boundary conditions.**Following forcing, initial and boundary conditions were applied as shown in Equation (19). We understand that physical applications are more interested in obtaining solitary solutions [29]. However, this algorithm requires significant modifications, such as working with conditions at infinity, to obtain solitary solutions, which is part of ongoing work. In our target application—equation discovery—observation data are available only over a finite domain.

**Solitary solution.**Even though the algorithm in its current state cannot obtain a solitary solution directly, we perform a series of experiments that allow us to obtain the solitary solution using periodic boundary conditions. As the first step, we take the solitary solution in the form of Equation (20).

## 6. Burgers Equation and DeepXDE Comparison

## 7. Conclusions

- It can solve ODE and PDE without the involvement of an expert after the algorithm launch, which is most useful for data-driven equation discovery methods;
- It has good precision for equation solution applications and has tools to trade the precision with integration time in both directions;
- It has a flexible modular structure. The modules could be replaced to achieve better speed or better precision.

- More machine learning approaches to differential equation initial-boundary value problems that allow solving non-canonical boundary-value problems, and a wider class of problems to move toward better equation discovery using automated solutions;
- Reduced optimization times;
- Possibility to use different parameterized models.

- Extended optimization time, which in some cases makes the discovery process non-viable;
- To work with physical problems, it is necessary to be able to work with models that allow reproducing special functions, including non-differentiable ones;
- To work with physical problems, the extension of boundary condition types is required.

- Use of the power of GPU to perform optimization using fast memory and built-in matrix instructions;
- Better usage of initial approximation;
- Usage of the “lazy computation” mode, i.e., the precompiled computational graph.

- The optimization problem statement using weak formulation to expand the possible class of solved equations;
- System solutions in strong and weak forms;

## Funding

## Data Availability Statement

## Conflicts of Interest

## Appendix A. Painlevé Boundary-Value Problems

## Appendix B. Solution Plots

**Figure A2.**Solution to Painlevé PIII transcendent Equation (A3).

**Figure A3.**Solution to wave Equation (14).

**Figure A4.**Solution to the non-physical initial-boundary value problem of the KdV equation, as described by Equation (19).

**Figure A5.**Solution to the non-physical initial-boundary value problem of the KdV equation, as described by Equation (21).

## References

- Rao, R.; Lin, Z.; Ai, X.; Wu, J. Synchronization of epidemic systems with Neumann boundary value under delayed impulse. Mathematics
**2022**, 10, 2064. [Google Scholar] [CrossRef] - Zhao, Y.; Wang, L. Practical Exponential Stability of Impulsive Stochastic Food Chain System with Time-Varying Delays. Mathematics
**2023**, 11, 147. [Google Scholar] [CrossRef] - Maslyaev, M.; Hvatov, A.; Kalyuzhnaya, A.V. Partial differential equations discovery with EPDE framework: application for real and synthetic data. J. Comput. Sci.
**2021**, 53, 101345. [Google Scholar] [CrossRef] - Rudy, S.H.; Brunton, S.L.; Proctor, J.L.; Kutz, J.N. Data-driven discovery of partial differential equations. Sci. Adv.
**2017**, 3, e1602614. [Google Scholar] [CrossRef] [Green Version] - Long, Z.; Lu, Y.; Dong, B. PDE-Net 2.0: Learning PDEs from data with a numeric-symbolic hybrid deep network. J. Comput. Phys.
**2019**, 399, 108925. [Google Scholar] [CrossRef] [Green Version] - Rackauckas, C.; Nie, Q. Confederated modular differential equation APIs for accelerated algorithm development and benchmarking. Adv. Eng. Softw.
**2019**, 132, 1–6. [Google Scholar] [CrossRef] [Green Version] - Hindmarsh, A.C.; Brown, P.N.; Grant, K.E.; Lee, S.L.; Serban, R.; Shumaker, D.E.; Woodward, C.S. SUNDIALS: Suite of nonlinear and differential/algebraic equation solvers. ACM Trans. Math. Softw. (TOMS)
**2005**, 31, 363–396. [Google Scholar] [CrossRef] - Morton, K.W.; Mayers, D.F. Numerical Solution of Partial Differential Equations: An Introduction; Cambridge University Press: Cambridge, UK, 2005. [Google Scholar]
- Thomas, J.W. Numerical Partial Differential Equations: Finite Difference Methods; Springer Science & Business Media: Berlin/Heidelberg, Germany, 2013; Volume 22. [Google Scholar]
- Ŝolín, P. Partial Differential Equations and the Finite Element Method; John Wiley & Sons: Hoboken, NJ, USA, 2005. [Google Scholar]
- Pavlovic, A.; Fragassa, C. Geometry optimization by fem simulation of the automatic changing gear. Rep. Mech. Eng.
**2020**, 1, 199–205. [Google Scholar] [CrossRef] - Scroggs, M.W.; Baratta, I.A.; Richardson, C.N.; Wells, G.N. Basix: A runtime finite element basis evaluation library. J. Open Source Softw.
**2022**, 7, 3982. [Google Scholar] [CrossRef] - Burns, K.J.; Vasil, G.M.; Oishi, J.S.; Lecoanet, D.; Brown, B.P. Dedalus: A flexible framework for numerical simulations with spectral methods. Phys. Rev. Res.
**2020**, 2, 023068. [Google Scholar] [CrossRef] [Green Version] - Li, Z.; Kovachki, N.; Azizzadenesheli, K.; Liu, B.; Bhattacharya, K.; Stuart, A.; Anandkumar, A. Neural operator: Graph kernel network for partial differential equations. arXiv
**2020**, arXiv:2003.03485. [Google Scholar] - Li, Z.; Kovachki, N.; Azizzadenesheli, K.; Liu, B.; Bhattacharya, K.; Stuart, A.; Anandkumar, A. Fourier neural operator for parametric partial differential equations. arXiv
**2020**, arXiv:2010.08895. [Google Scholar] - Zwillinger, D.; Dobrushkin, V. Handbook of Differential Equations; CRC Press: Boca Raton, FL, USA, 2021. [Google Scholar]
- Rackauckas, C.; Ma, Y.; Martensen, J.; Warner, C.; Zubov, K.; Supekar, R.; Skinner, D.; Ramadhan, A. Universal Differential Equations for Scientific Machine Learning. arXiv
**2020**, arXiv:2001.04385. [Google Scholar] - Hindmarsh, A.C. ODEPACK, a systematized collection of ODE solvers. In Scientific Computing; Lawrence Livermore National Laboratory: Livermore, CA, USA, 1983; pp. 55–64. [Google Scholar]
- Hindmarsh, A.C. ODEPACK: Ordinary Differential Equation Solver Library; Astrophysics Source Code Library: Record ascl:1905.021. May 2019. Available online: https://ui.adsabs.harvard.edu/abs/2019ascl.soft05021H (accessed on 7 February 2023).
- Ahnert, K.; Mulansky, M. Odeint–solving ordinary differential equations in C++. AIP Conf. Proc.
**2011**, 1389, 1586–1589. [Google Scholar] - Rackauckas, C.; Innes, M.; Ma, Y.; Bettencourt, J.; White, L.; Dixit, V. Diffeqflux.jl-A julia library for neural differential equations. arXiv
**2019**, arXiv:1902.02376. [Google Scholar] - Liu, S.; Wang, T.; Zhang, Y. A Functional Package for Automatic Solution of Ordinary Differential Equations with Spectral Methods. arXiv
**2016**, arXiv:1608.04815. [Google Scholar] - Raissi, M.; Perdikaris, P.; Karniadakis, G.E. Physics-informed neural networks: A deep learning framework for solving forward and inverse problems involving nonlinear partial differential equations. J. Comput. Phys.
**2019**, 378, 686–707. [Google Scholar] [CrossRef] - Lu, L.; Jin, P.; Karniadakis, G.E. Deeponet: Learning nonlinear operators for identifying differential equations based on the universal approximation theorem of operators. arXiv
**2019**, arXiv:1910.03193. [Google Scholar] - Sirignano, J.; Spiliopoulos, K. DGM: A deep learning algorithm for solving partial differential equations. J. Comput. Phys.
**2018**, 375, 1339–1364. [Google Scholar] [CrossRef] [Green Version] - Czarnecki, W.M.; Osindero, S.; Jaderberg, M.; Swirszcz, G.; Pascanu, R. Sobolev Training for Neural Networks. In Proceedings of the NIPS, Long Beach, CA, USA, 4–9 December 2017. [Google Scholar]
- Lu, L.; Meng, X.; Mao, Z.; Karniadakis, G.E. DeepXDE: A deep learning library for solving differential equations. SIAM Rev.
**2021**, 63, 208–228. [Google Scholar] [CrossRef] - Maslyaev, M.; Hvatov, A. Solver-Based Fitness Function for the Data-Driven Evolutionary Discovery of Partial Differential Equations. In Proceedings of the 2022 IEEE Congress on Evolutionary Computation (CEC), Padua, Italy, 18–23 July 2022; pp. 1–8. [Google Scholar]
- Nguyen, L.T.K. Modified homogeneous balance method: Applications and new solutions. Chaos Solitons Fractals
**2015**, 73, 148–155. [Google Scholar] [CrossRef] - Arnold, D.N.; Winther, R. A superconvergent finite element method for the Korteweg-de Vries equation. Math. Comput.
**1982**, 38, 23–36. [Google Scholar] [CrossRef] [Green Version] - Göküzüm, F.S.; Nguyen, L.T.K.; Keip, M.A. An artificial neural network based solution scheme for periodic computational homogenization of electrostatic problems. Math. Comput. Appl.
**2019**, 24, 40. [Google Scholar] [CrossRef] [Green Version] - Wang, S.; Wang, H.; Perdikaris, P. On the eigenvector bias of Fourier feature networks: From regression to solving multi-scale PDEs with physics-informed neural networks. Comput. Methods Appl. Mech. Eng.
**2021**, 384, 113938. [Google Scholar] [CrossRef] - Wang, S.; Yu, X.; Perdikaris, P. When and why PINNs fail to train: A neural tangent kernel perspective. J. Comput. Phys.
**2022**, 449, 110768. [Google Scholar] [CrossRef]

**Figure 1.**Rough classification of differential equation solvers. A classification that correspondingly may be applied to the equation is shown with ODE (violet), PDE (grey), or both.

**Figure 4.**Legendre polynomial solution time in seconds (

**left**) and solution error (

**right**). The type is the order of polynomial n in Equation (12); different colors (

`cache = false`) and (

`cache = true`) cases are shown.

**Figure 5.**Legendre polynomial solution time (

**left**) and solution error (

**right**). The order of the polynomial n in Equation (12) is indicated by the type of curve, while different colors represent different approximations, i.e., neural network-based and matrix-based.

**Figure 6.**Scheme of the solution of the Painlevé transcendent “complexity”. Each class of functions contains the previous one. The color coding indicates the predicted relative “performance” of a conventional solver for each transcendent.

**Figure 7.**A summary of Painlevé I–III experiment runs. Different colors represent runs with and without an initial guess.

**Figure 8.**Mean time (in seconds) in the logarithmic scale of the optimization for each Painlevé transcendent (

**left**) and mean error ratio (

**right**) (1.0 is the maximal error for each equation); the maximal error for PI–PII is at the 10 grid point, which is not shown.

**Figure 9.**Summary of all PDE experiments: upper row errors and lower time. From (

**left**) to (

**right**)—wave equation, heat equation, and Korteweg–de Vries equation.

**Figure 10.**Results of the numerical solution to problem Equation (15) for a different number of discretization points. Computation time (

**left**) and RMSE (

**right**). All experiments were performed with

`cache=True`.

**Figure 12.**RMSE with respect to the analytical solution: orange—proposed approach without cache, blue—with cache, green—DeepXDE without additional LBFGS refinement, red—with LBFGS refinement.

**Figure 13.**Optimization times for different methods: orange—proposed approach without cache, blue—with cache, green—DeepXDE without additional LBFGS refinement, red—with LBFGS refinement.

Module | DeepXDE | Proposed Approach |
---|---|---|

Approximator | NN (TensorFlow—dense,Fourier kernel layers) | Parameterized model ( PyTorch) |

Differentiation | Autograd | Autograd, numerical differentiation |

Operator form | Constant coefficients, variable coefficients (no examples) | Time- and spatial- variable coefficients |

BC form | Dirichlet, Neumann, Robin, IC, GeneralBC (no examples) | Arbitrary |
